LS8-50002K
| SHOCK LOCATION | SKI SHOCK KIT | |
|---|---|---|
| SHOCK WEIGHT (lbs) | 9.00 | |
| SHOCK | LS8-50002 | |
| QTY | 2 | |
LS8-50002
| SHOCK LOCATION | SKI | |
|---|---|---|
| SHOCK WEIGHT (lbs) | 4.50 | |
| SHOCK LENGTH OPEN | (MM) | 425.0 |
| (INCH) | 16.7 | |
| SHOCK LENGTH CLOSED | (MM) | 295.0 |
| (INCH) | 11.6 | |
| SHOCK STROKE LENGTH | (MM) | 130.0 |
| (INCH) | 5.1 | |
| EYELET TOP ID | (MM) | 10.3 |
| (INCH) | 0.4 | |
| EYELET TOP WIDTH | (MM) | 30.32 |
| (INCH) | 1.2 | |
| EYELET BOTTOM ID | (MM) | 12.2 |
| (INCH) | 0.5 | |
| EYELET BOTTOM WIDTH | (MM) | 17.8 |
| (INCH) | 0.7 | |
| SPRING DIAMETER | (MM) | 74.5 |
| (INCH) | 2.9 | |
